DESCRIPTION
|
NON REAL TIME MODE
|
REAL TIME MODE
|
|
VIDEO INPUTS
|
|
|
|
SDI (SD, HD) Embedded audio
|
8
|
8
|
|
HDMI (SD, HD)
|
2
|
2
|
|
Select any 8 inputs at a time
|
|
|
|
VIDEO OUTPUTS
|
|
|
|
SDI (SD, HD) Embedded audio
|
8
|
8
|
|
HDMI (SD, HD)
|
2
|
2
|
|
All outputs simultaneous
|
|
|
|
VIDEO INPUT PROCESSING
|
|
|
|
Total video input for switching simultaneous
|
8
|
8
|
|
Simultaneous live video sources (PIP's)
|
8
|
2 RT mode / 6 Non RT mode
|
|
Multiviewer
|
|
|
|
Video delay
|
8 frames
|
2 frames
|
|
Multi resolution combinations
|
|
|
|
VIDEO OUTPUT PROCESSING
|
|
|
|
Hardware based scaling conversion
|
8th SDI Output is down converted PGM
|
|
PRV (B bus) hardware video output
|
4th SDI Output is Preview out as per output resolution
|
|
TRANSITIONS
|
|
|
|
All sophisticated 2D/3D transition effects
|
HD 6000+, SD 4:3 3000+
|
--
|
|
Effects type
|
New effects with up to 8 inputs
All Striker effects
|
--
|
|
CONTROLS
|
|
|
|
GPI/O
|
15 Pin DSub with 6 IN and 2 OUT
|
|
RJ 45 for Audio Link
|
Audio and Video breakout box connection
|
|
Tally Support
|
10 inputs (2 HDMI - 8 SDI)
|
|
Genlock REF IN with LOOP OUT (Bi/Tri level)
|
|
|
Bypass (Video) with power ON
|
Any 1 input detected will bypassed on all outputs
|
|
Bypass (Audio) with power ON
|
Any 1 input detected will bypassed on all outputs
|
|
Built-in frame synchronizers
|
|
|
AUDIO INPUTS
|
|
|
|
Analog
|
4 x independent XLR balanced (4 Channel/2 Stereo)
|
|
MIC
|
1x 6.3mm Jack
|
|
* Digital (Optional)
|
2 x XLR each Stereo AES/EBU (1 Stereo on each connector)
|
