DESCRIPTION
|
STRIKER 325
|
STRIKER 450
|
Standard
|
HD/SD and Analog
|
HD/SD and Analog
|
VIDEO INPUTS
|
|
|
HD and/SD SDI
|
4
|
4
|
HDMI with embedded audio
|
2
|
2
|
Composite (CVBS) Analog
|
4
|
4
|
AUDIO INPUTS
|
|
|
Number of audio
|
4 Channel/2 Stereo XLR Balanced
+ HDMI embedded
|
4 Channel/2 Stereo XLR Balanced
+ HDMI embedded
|
Microphone (6.3 mm Jack)
|
1
|
1
|
VIDEO OUTPUTS
|
|
|
HD/SD - SDI Program (PGM) with embedded audio
|
2 Parallel
|
2 Parallel
|
HD/SD - SDI Preview (PRV) with embedded audio
|
2 Parallel
|
2 Parallel
|
Composite (CVBS) Analog Program (PGM
|
2 Parallel (HD to SD Down converted)
|
2 Parallel (HD to SD Down converted)
|
Composite (CVBS) Analog Preview (PRV)
|
2 Parallel (HD to SD Down converted)
|
2 Parallel (HD to SD Down converted)
|
HDMI with embedded audio
|
1
|
1
|
Number of audio
|
2 Stereo XLR Balanced
|
2 Stereo XLR Balanced
|
Headphone (6.3 mm Jack)
|
1
|
1
|
OTHER FUNCTIONS
|
|
|
Inbuilt recording
|
|
|
Number of transitions
|
1500
|
2000
|
Transition Type
|
2D + 3D
|
2D + 3D
|
FX Editor
|
|
|
Web streaming
|
|
|
Digital Players (Movie)
|
2
|
2
|
Digital Players (Bitmap/Titles)
|
2
|
2
|
FX Sequencer
|
|
|
Media Sequencer
|
|
|
Mix HD/SD resolution
|
|
|
Photo Editing
|
PhotoArt
|
PhotoArt
|
Audio Dubbing
|
DigiMix
|
DigiMix
|
Overlay Logos
|
3
|
3
|
Ticker (Multi language, uni direction)
|
|
|
Bypass (Video and Audio)
|
|
|
SOFTWARE MODES
|
|
|
3D Shapes support (Page turn, Sphere, Cube etc.)
|
|
(Striker Mode)
|
3D Object support: Shader materials like (Metal, Glass)
|
|
|
3D Text
|
|
|
GoLive LE / GoLive PRO / Striker mode
|
GoLive PRO
|
GoLive PRO + Striker
|
SmartCut Pro
|
|
|
VGA module with VGA and CVBS loop out | VGA will be Shared with
4th CVBS input. Will work without upgrading to 4 CVBS function
|
Optional (VGA module) `.35,000/-*
|
Optional (VGA module) `.35,000/-*
|
